Heating transformers 61 - 70 kVA*

Secondary permanent current 1430 ... 13.000 A
Secondary voltages 3,4 ... 49,0 V

*The picture is an example.


EnvelopeMake a request Übersicht und Maßblätter

Heating transformers 71 - 80 kVA*

Secondary permanent current 1130 ... 14.900 A
Secondary voltages 4,4 ... 66,7 V

*The picture is an example.


EnvelopeMake a request Übersicht und Maßblätter

Heating transformers 81 - 90 kVA*

Secondary permanent current 800 ... 15.600 A
Secondary voltages 3,8 ... 111,8 V

*The picture is an example.


EnvelopeMake a request Übersicht und Maßblätter

Heating transformers 91 - 100 kVA*

Secondary permanent current 500 ... 12.000 A
Secondary voltages 4,0 ... 200,0 V

*The picture is an example.


EnvelopeMake a request Übersicht und Maßblätter
Picture MFDC transformer series 2MF8

Series 2MF8-L

Series for long current times and high duty cycles

  • Conductive heating
  • Heating processes
  • Flash butt welding
  • Seam welding
  • ...
Power (50% d.c.) 157 ... 491 kVA
Secondary voltages 6,4 ... 21,4 V
Secondary permanent current 13,0 kA
EnvelopeMake a request FileDownload datasheet
Picture MFDC transformer series 3MF8

Series 3MF8-L

Series for long current times and high duty cycles

  • Conductive heating
  • Heating processes
  • Flash butt welding
  • Seam welding
  • ...
Power (50% d.c.) 235 ... 735 kVA
Secondary voltages 6,4 ... 21,4 V
Secondary permanent current 19,5 kA
EnvelopeMake a request FileDownload datasheet
Picture MFDC transformer series 4MF8

Series 4MF8-L

Series for long current times and high duty cycles

  • Conductive heating
  • Heating processes
  • Flash butt welding
  • Seam welding
  • ...
Power (50% d.c.) 314 ... 980 kVA
Secondary voltages 6,4 ... 21,4 V
Secondary permanent current 26,0 kA
EnvelopeMake a request FileDownload datasheet
Picture MFDC transformer series 6MF8

Series 6MF8-L

Series for long current times and high duty cycles

  • Conductive heating
  • Heating processes
  • Flash butt welding
  • Seam welding
  • ...
Power (50% d.c.) 471 ... 1471 kVA
Secondary voltages 6,4 ... 21,4 V
Secondary permanent current 39,0 kA
EnvelopeMake a request FileDownload datasheet
Picture MFDC transformer series 8MF8

Series 8MF8-L

Series for long current times and high duty cycles

  • Conductive heating
  • Heating processes
  • Flash butt welding
  • Seam welding
  • ...
Power (50% d.c.) 628 ... 1960 kVA
Secondary voltages 6,4 ... 21,4 V
Secondary permanent current 52,0 kA
EnvelopeMake a request FileDownload datasheet
Picture MFDC transformer series MF8

Series MF8-L

  • MF transformer for continuous operation, long duty cycles and long welding and process times
  • MF solution for seam welding for continuous and pulse/pause mode
Power (50% d.c.) 78 ... 245 kVA
Secondary voltages 6,4 ... 21,4 V
Secondary permanent current 6,5 kA

For details on sizing please contact us.
